250 kg (551 lb)
ND 1142 – Vida Care
*Illustrative image only. *Subject to variations. Optional accessories available.
Structure
Structure: High-strength tubular carbon steel construction
Chassi: Carbon steel tubular frame
Metal Structure Surface Finish: anti-rust chemical treatment and electrostatic powder coating finish. 1,500-hour salt spray test performed by an INMETRO-accredited laboratory.
Bed
Estrado: está compuesto por una estructura de tubos de 50 x 30 x 1,2 mm con láminas de 3/8”. La estructura metálica del lecho consiste en cuatro secciones articuladas fabricadas con una estructura de tubos de 30 x 30 x 1,2 mm con bandeja de 3/8”.
Bed Platform: carbon steel platform articulated in 4 sections. Cremalheira com duas posições de regulagem na peseira.
Siderails
Full-length retractable side rails with escape-release design, equipped with a safety locking mechanism, integrated Backrest Angle Indicator, and Trendelenburg Angle Indicator.
Movement and Elevation
Fowler Backrest: 80º
Fowler Legrest:25º
Trendelenburg: 12º
Reverse Trendelenburg: -12º
Maximum Height: 68 cm (27″)
Minimum Height: 33 cm (13″)
Lifting system with 4 cranks, providing smooth, silent, and safe movement.
Operation: cranks positioned on the footboard of the bed.
Movements: Fowler, Semi-Fowler, Trendelenburg, Reverse Trendelenburg, Chair Position, Vascular Position, Cardiac Position, Abdominal Compensation System, and Auto Contour.
Dimensions
Bed platform: 195 x 83 cm (77 x 33 in)
Standard Accessories
- Foley Bag Holder
- Mattress Retainer Supports
- 5″ Casters with Diagonal Braking System
Mattress Included
Mattress Registration: 80581990013
Model: MT-672
D-28 foam, waterproof hospital-grade synthetic leather upholstery, seamless welded finish, and compatible with the bed dimensions
